iCAD Assembler

Designing with iCAD Assembler

our free CAD tool

Our construction tool iCAD Assembler offers the optimal supplement to our construction kit. Only with the combination of hard- and software complex requirements can be realized in a simple way - not only in rational mechanical engineering.

Your advantages:

  • 3D design tool for MiniTec components
  • Easy handling without CAD knowledge
  • Electronic catalog and configurators included
  • True to scale construction drawing and material parts list.
  • Direct interface to all common CAD systems like: Mechanical, Proengineer, Solid Works etc.
  • Integrated deflection analysis

System requirements:

  • IBM or compatible PC with min. 2GHz, 2GB RAM
  • Windows 8 | 10 | 11

Installation instructions depending on the download variant:

  • Exe.file: start setup.exe, follow the installation instructions and then start the program with ccAssembler.exe
  • Zip.file: unzip file on the PC and then start the program with ccAssembler.exe


iCAD Assembler (zip file)   (1 GB)
iCAD Assembler (exe file)   (802 MB)
